Ex lagana silicon 210mm et cellulis monocrystallicis PERC, usque ad 425Wp potentiae emissi cum consilio porttitor, et efficientia usque ad 21.3%. pertingere potest.
| Electrical Specification | |||||||||||
| OMNIBUS Type | M1821T648-405W | M1821T648-410W | M1821T648-415W | M1821T648-420W | M1821T648-425W | ||||||
| Test signa | STC | NOCT | STC | NOCT | STC | NOCT | STC | NOCT | STC | NOCT | |
| Maximum Power | Pmax(W) | 405 | 306 | 410 | 309 | 415 | 312 | 420 | 317 | 425 | 321 |
| Maximum Power intentione | Vmp(V) | 41.3 | 38.3 | 41.5 | 38.5 | 41.7 | 38.7 | 42 | 39.2 | 42.2 | 39.5 |
| Maximum Power Current | Imp(A) | 9.82 | 7.99 | 9.87 | 8.03 | 9.94 | 8.07 | 10.1 | 8.1 | 10.08 | 8.13 |
| Open Circuit Voltage | Voc(V) | 49.7 | 46.8 | 49.8 | 46.9 | 50 | 47.1 | 50.1 | 47.1 | 50.2 | 47.2 |
| Brevis Circuitu Current | Isc(A) | 10.5 | 8.46 | 10.53 | 8.49 | 10.55 | 8.5 | 10.58 | 8.53 | 10.61 | 8.55 |
| Module Efficens | (%) | 20.3 | 20.5 | 20.8 | 21 | 21.3 | |||||
| Virtus output tolerantia | (%) | 0-±5 | |||||||||
| Per tolerantia Power Test | (W) | ±3 | |||||||||
| (STC*)* irradiatio 1000W/㎡，Modulus Temperature 25℃，Aeris Missa 1.5 (NOCT*)* Irradiantia 800W/㎡，Ambient Temperature 20℃，Velitas 1m/s" | |||||||||||
| Mechanica Data | |
| Numerus Cellulae | 144Cells |
| Dimensiones moduli L*W*H（mm） | 1762×1134×30mm |
| Pondus kg | 21.8kg |
| vitrum | 3.2 mm Transmissio High; |
| AR Coated Calore vitro confirmati | |
| Encapsulant materiales | Black-White |
| Backsheet | EVA/POE |
| Artus | 30mm Anodized Aluminium Alloy |
| J-BOX | IP68 aestimavit |
| Cable | Photovoltaic Technology Cable 4.0mm² |
| Portrait: 350/280 mm | |
| Longitudo potest nativus | |
| Connector | MC4 EVO2/TS4* |
| * Quaeso ad regional datasheet ad certum iungo | |
| Temperature Ratings | |
| Temperature Ratings | 43(±2℃) |
| Temperature Coefficiens of P | -0.34%/ |
| Temperature Coefficiens Vocis | -0.25%/℃ |
| Temperature Coefficiens Isc | -0.04%/ |
| Maximum Ratings | |
| Temperature operational | -40- 85℃ |
| Maxime Ratio intentione | 1500V DC |
| Max Series Fuse Rating | 20A |
| Packaging configurationis | |
| OMNIBUS per box | 36pieces |
| OMNIBUS per 40' continens | 936pieces |
